Tessera T1 LED Processor
Introduction

DESIGNED FOR CREATIVITY

​
T1 is ideal for small creative shows requiring maximum flexibility over fixture layout and input processing while not requiring a large number of output pixels.
​
Perfect for shows using coarse pitch panels and strips/tiles.

DMX512, Art-Net and sACN control of many control parameters, including real-time control of fixture group position, rotation and colour

Status and Power Indicators

2 x Fans with Replaceable Filters

2 x USB2.0

Ports

Tessera
Output

Management

Ethernet

DMX In + Thru

Tessera
Output

Local User Interface

Switched
Auto-Ranging Mains Input

Front & Back

TECH SPECS

Tech Specs
INPUTS

DVI-D

with reclocked thru port

​

Up to 1920 x 1080 @ 60Hz (148.5MHz pixel clock).


Support for RGB and YCbCr colour spaces.



HDMI support with suitable adapter. No HDCP support.

OUTPUTS

1 x 1G Tessera output port



Supports a nominal 525K pixels at 8 bits per colour, 60Hz frame rate.

10 and 12 bits per colour output is supported at reduced pixel counts.

Pixel count may be reduced for certain fixture types.

​

Neutrik EtherCON connectors, compatible with standard RJ45.

​

FRONT-END PROCESSING

All processing at 12 bits per colour channel (36 bits per pixel)

​

Per-input proc-amp style colour controls with histogram preview

​

Controls include hue, saturation, brightness, contrast and individual red, green and blue shadow and highlight.



Single processing pipeline featuring clipping and up-/down-scaling, with clean switching between settings

​

Processing pipeline is disabled when operating in low latency mode, or when non-standard canvas resolutions are enabled.

​

Full HD 1920x1080 standard canvas



Optional non-standard canvas sizes: 1600x1200, 2880x720, 720x2880, 1080x1920

​

Use of non-standard canvas sizes disables some front-end processing, see above.

FIXTURE PROCESSING

Free placement of fixtures anywhere in the canvas

​

Free rotation of fixtures to any angle

​

Multiple fixture types per project

​

Automatic interpolation of different pixel pitches to make content appear at the same physical size across all fixtures

​

Interpolation can be disabled for 1:1 output on all fixture types. The content appears at normal size on the finest pixel pitch fixtures, and is scaled to match on those with coarser pixel pitches.

​

Nominal 525000 pixel capacity

​

Nominal capacity at 60Hz frame rate and 8 bits per colour output. Capacity increases proportionally for lower frame rates and decreases proportionally for 10 or 12 bits per colour output.

​

Rotation of some fixture types may result in reduced capacity. Fixtures smaller than 16px in either dimension have additional processing overhead and therefore result in reduced capacity.

​

Up to 500 fixtures per project

GENLOCK

Lock to source or an internal timing reference

​

The frame rate of the internal reference can be set by the user.

​

Frame rates from 23.98 to 60Hz are supported.

​

The processor automatically locks to the video input when in low latency mode, or using non-standard canvas sizes.

​

Genlock from source to the LED refresh

LATENCY

3 frames end-to-end system latency with all features enabled

​

2 frames end-to-end system latency in low-latency mode

​

Some front-end processing and genlock features are disabled in low latency mode.

​

When using legacy fixture types with constant current driver ICs, the end-to-end latency is one frame less.

​

Latency is measured in multiples of the frame rate period of the genlock source.

USER INTERFACE

Local management using monitor, keyboard and mouse

​

DP++ monitor output supports DVI, HDMI and VGA using a suitable adapter. Monitors from 1280x1024 up to 1920x1080 are supported.

​

2 x USB2.0 on front and 2 x USB 2.0 on rear for keyboard and mouse. Can also be used for USB memory sticks for firmware reload and project backup.

​

Remote management from Tessera Remote on Windows PC or Mac OS X via management network ports

​

1 x Gigabit Ethernet management network port, also used for live control (see below). Neutrik EtherCON connector, compatible with standard RJ45.

​

7 x status LEDs and power LED on front

LIVE CONTROL

DMX-512A on 5-pin XLR in and thru

​

eDMX (Art-Net and sACN) and Tessera Control app via management network ports

​

2 x Gigabit Ethernet management network ports connected internally as a switch. Also used for remote management (see above). Neutrik EtherCON connectors, compatible with standard RJ45.

ELECTRICAL

Switched autoranging power supply

​

100 - 240V AC

47Hz - 60Hz

0.4 - 0.2A

MECHANICAL

1U 19" rack form factor

​

Dimensions (W x H x L):

431.8mm x 44.5mm x 342.9mm

19” x 1.75” x 13.5”

​

Net weight:

2kg

4.4lbs

WARRANTY

2 years

CERTIFICATION

ETL/cETL, CE and RoHS compliant
